LAPP 2170560 UNITRONIC BUS IS PVC hybrid cable carries ISOBUS data and power between agricultural vehicles and implements. Black PVC sheath with 2 x 6, 2 x 2.5 and 4 x 0.5 mm2 conductors.
Sold by the metre as unterminated bulk cable. Connectors and finished harness assembly are not included.
LAPP UNITRONIC BUS IS PVC ISOBUS Cable | 2170560 | per metre
LAPP 2170560 UNITRONIC BUS IS PVC bulk ISOBUS cable, sold by the metre. Black PVC sheath, 2 x 6 + 2 x 2.5 + 4 x 0.5 mm2 conductors, nominal diameter 15.6 mm. Unterminated cable, not a complete harness.
LAPP 2170560 ISOBUS PVC bulk cable
Hybrid data and power cable for agricultural tractor-to-implement connections, specified by LAPP to ISO 11783-2:2012.
- Conductors: 2 x 6 + 2 x 2.5 + 4 x 0.5 mm2, fine-wired bare copper
- Black PVC outer sheath; nominal outside diameter 15.6 mm
- Characteristic impedance: 75 ohms
- Peak operating voltage: 60 V
- PVC temperature range: -30 to +85 degrees C
- Minimum bend radius: 10 x diameter fixed, 15 x diameter occasionally moved
- UV, oil, benzine and diesel resistant; flame retardant to IEC 60332-1
Not for continuous flexing. The occasionally moved bend radius is not a continuous-flex rating.
Quantity is in metres. Confirm required continuous length before ordering. This is bulk cable without connectors, not a plug-and-play harness or proof of machine compatibility. Article 2170560 is PVC; PUR article 2170561 is a different product.
Technical specifications are attributed to LAPP's UNITRONIC BUS IS manufacturer catalogue.
